ORDERING CODE
EK-FF1-TP
DESCRIPTION
16-fold KNX binary output 16(10)A for switching and control of loads or 8-fold KNX actuator for control of drives for motorized blinds, shutters or curtains. Mounting in distribution board on EN 60715 rail (8 modular units, each 18 mm). To be used in KNX installations for home and building automation.
FUNCTIONS / CHARACTERISTICS
(BINARY OUTPUT)
ON/OFF switching of individual loads or groups of loads
Configurable as normally open or normally closed switch
Logical gates and forced mode for each channel
Manual control by membrane pushbuttons
Status feedback of output channels through LEDs
Switching pushbutton manual/automatic mode
Block function for each channel
• Time scheduling: switching delay for on and off, staircase lighting function with warning signal
Integration in scenarios
Operating hours counter configurable via bus
(BLIND ACTUATOR)
Full up and down run
Partial run with stop position from 0 to 100% of the length of the run
Position setting (change during the operation of the preset position)
Adjust the inclination of the slats (for blinds)
Integration in scenarios
Automatic control for protection against direct sunlight
Automatic control for protection against weather conditions (rain, wind, frost)
CONFIGURATION AND COMMISSIONING
A detailed description of the parameters can be found in the application manual of the device. Configuration and commissioning require ETS4 or later versions
